A railway built for difficult country
Beginning in the late nineteenth century, Maine developed an unusual railway network whose rails stood only two feet apart. Smaller equipment and tighter curves made these lines practical in terrain where a full-size railroad could be costly to build.
Five principal systems served rural parts of western and central Maine: the Sandy River & Rangeley Lakes, Bridgton & Saco River, Monson, Kennebec Central, and Wiscasset & Quebec. Their compact locomotives and cars linked communities and resource industries with larger standard-gauge railroads.
What “two-foot gauge” means
Gauge is the distance between the inner faces of the rails. Maine’s best-known narrow-gauge lines used a 24-inch gauge, compared with the 56½-inch standard gauge widely used in the United States and United Kingdom.
From Wales to New England
The American two-foot idea was influenced by the Ffestiniog Railway in Wales. George Mansfield of Massachusetts saw that railway during the 1870s and recognized how a very narrow gauge could reduce construction costs and negotiate rough terrain.
In 1875 Mansfield established the Billerica & Bedford Railroad in Massachusetts, the first commercial two-footer in the United States. Although that venture failed, its equipment and Mansfield’s experience moved north. In 1879 he helped organize the railroad that became the Sandy River & Rangeley Lakes system.
The five principal systems
Sandy River & Rangeley Lakes
The largest system connected Farmington with Strong, Phillips, and Rangeley. It handled both freight and passengers until 1935.
Bridgton & Saco River
Built from Hiram in 1882 and later extended to Harrison, it served the Bridgton area. Its last train ran in September 1941.
Monson Railroad
Known as the “two by six” because it was about six miles long, this slate-hauling line connected the quarries near Monson with Monson Junction.
Kennebec Central
Opened in 1890 to serve the National Soldiers’ Home at Togus, it carried visitors and coal from what is now Randolph.
Wiscasset & Quebec
Later known as the Wiscasset, Waterville & Farmington, it followed the Sheepscot River and eventually linked Wiscasset with Albion and Winslow.
A shared purpose
Though their traffic differed, the lines connected isolated districts with markets, larger railways, public institutions, and regional centers.
Sandy River & Rangeley Lakes
The Sandy River & Rangeley Lakes grew into a substantial system. At Farmington it interchanged with the standard-gauge Maine Central, then ran north through Strong and Phillips toward Rangeley. Its branches included the Franklin & Megantic, Phillips & Rangeley, and Kingfield & Dead River lines.
It carried passengers as well as freight and came closer than Maine’s other two-footers to the operating scale of a conventional railroad. The line ceased operations in 1935.
Bridgton & Saco River
Chartered in 1881, the Bridgton & Saco River was constructed from Hiram beginning in July 1882. Its initial 16 miles were completed rapidly, and an additional five miles reached Harrison in 1889.
The Maine Central took over the railroad in 1912. The Bridgton & Harrison Railway Company acquired it in 1928, but declining business led to the abandonment of the route between Bridgton and Harrison. Excursions and growing enthusiasm for railway preservation prolonged operations into the early 1940s.
Monson and Kennebec Central
The Monson Railroad primarily moved slate from quarries near Monson to the junction with the larger rail network. It was abandoned in 1943. Two locomotives, numbers 3 and 4, escaped scrapping and became important surviving examples of Maine’s narrow-gauge era.
The Kennebec Central had a specialized role. It connected the National Soldiers’ Home at Togus with the Kennebec River. Visitors used the line for weekly band concerts, baseball games, and other events; coal made up much of its freight traffic. Trucks eventually displaced that business, and the railway closed in 1929.
Wiscasset, Waterville & Farmington
The Wiscasset & Quebec received its charter in 1854, although construction did not begin until 1894. The plan envisioned commerce moving toward Quebec. The first 20 miles followed the Sheepscot River to Coopers Mills through Alna, Head Tide, and North Whitefield. The railroad reached Albion in 1895, creating a route of roughly 43½ miles.
A branch from Weeks Mills to Winslow was completed in 1902. Textile operations in North Vassalboro generated freight, while milk, cattle, grain, general merchandise, and passengers also traveled over the line.
The route was cut back from Winslow to North Vassalboro in 1912. Its final breakdown came in June 1933, when a train heading from Whitefield to Wiscasset encountered a broken outer rail near Iron Bridge and went down the bank toward the river. The remains were later scrapped.
What survives
Historic equipment, reconstructed track, workshops, stations, and operating demonstrations preserve portions of the two-foot story. The WW&F Railroad Museum in Alna has restored and replicated elements of the Wiscasset line, including railway equipment and several miles of track.
Surviving locomotives and cars also illuminate passenger travel. The 1901 “Rangeley,” built as a two-foot parlor car, served deluxe travel between Farmington and Rangeley before operating on the larger Sandy River & Rangeley Lakes system.
Why these railroads mattered
The two-footers were more than curiosities. They joined farms, quarries, mills, resorts, villages, and public institutions to regional transportation networks. Their history shows how railway technology was adapted to Maine’s terrain and dispersed settlement.
Additional resources
- Peter S. Barney, The Bridgton and Saco River: A Technical and Pictorial Review (1987).
- Peter S. Barney, Handcars, Railcars, and Railbuses of the Sandy River & Rangeley Lakes R.R. (1990).
- Robert C. Jones, Two Feet to the Lakes: The Bridgton & Saco River Railroad (circa 1993).
- Chris McChesney, Narrow Gauge in the Sheepscot Valley: A Comprehensive Guide to the Wiscasset, Waterville & Farmington Railway (2001–2003).
- Linwood W. Moody, The Maine Two-footers: The Story of the Two-foot Gauge Railroads of Maine (1959).
- Ellis Walker, Wiscasset, Waterville & Farmington Musings (2003).
- Ruby Crosby Wiggin, Albion on the Narrow Gauge (1964).
